EPES233 Outdoor Liquid Cooling Energy Storage Cabinet

The EPES233 Outdoor Liquid Cooling Energy Storage Cabinet is engineered to empower businesses with reliable, efficient, and safe energy management. At its core, the system utilizes high-density Lithium Iron Phosphate (LFP) battery technology, offering a substantial 233kWh capacity paired with a 105kW Power Conversion System (PCS). What sets the EPES233 apart is its intelligent liquid cooling and heating system, which maintains optimal battery temperatures even in extreme environments (-20°C to 50°C), significantly extending cycle life and enhancing performance compared to traditional air-cooled systems.

Designed for versatility, the EPES233 supports a wide range of applications including peak shaving, demand response, and backup power supply. Its "All-in-One" architecture integrates the battery, PCS, BMS, and fire suppression systems into a single, robust IP55-rated enclosure, simplifying installation and operation. With a cycle life exceeding 8,000 cycles and a comprehensive safety design featuring aerosol and pack-level immersion fire protection, the EPES233 is a secure investment for enterprises aiming for energy independence and sustainability.

Key Features:

• All-in-One Design: Integrated Battery, PCS, BMS, and Fire Suppression in one pre-assembled cabinet.
• Liquid Cooling Technology: Advanced thermal management ensures temperature uniformity (<2.78°C difference) for longer battery life.
• High Safety Standards: Multi-level fire protection including aerosol, pack-level immersion, and active warning systems.
• Flexible Operation: Supports peak shaving, time-of-use arbitrage, and seamless off-grid switching.
• Robust Build: IP55 ingress protection and C4 anti-corrosion grade for harsh outdoor durability.

Benefits:

• Lower Energy Costs: Maximize savings through peak-valley price arbitrage and improved PV self-consumption.
• Extended Lifespan: Liquid cooling maintains optimal cell health, delivering over 8,000 cycles at 95% DOD.
• Rapid Deployment: Pre-assembled unit reduces onsite installation time and labor costs.
• Grid Resilience: Provides reliable backup power during grid outages to protect critical loads.

Technical Specifications:
